Matrix LED headlights Audi A5

One of the most important laws of the road is to see and be seen. The Ingolstadt-based premium carmaker fulfills this maxim with innovative lighting technologies and combines them with highly expressive design.

Audi laser light

Audi laser light

Available for selected top models, Audi laser light doubles the range of the high beam. A small laser module in each headlight generates a light cone that extends several hundred meters as a spotlight. The monochromatic and coherent blue laser beam has a wavelength of 450 nanometers. A phosphor converter transforms it into white light suitable for roadway use with a color temperature of 5,500 Kelvin – ideal conditions for the human eye: Drivers enjoy greater contrast and tire less quickly. The laser spot, which is active at speeds of 70 km/h (43.5 mph) and above, also offers significant visibility and safety advantages. The laser spot dims automatically if the camera mounted on the windshield detects other cars within its range.

Digital matrix LED headlights

With the digital matrix LED headlights as top-of-the range equipment, Audi presents a worldwide first in a production vehicle: Broken down into minute pixels, their light can illuminate the road in high resolution. The design is based on a technology abbreviated as DMD (digital micromirror device) and is also used in many video projectors. At its heart is a small chip containing one million micromirrors, each of whose edge length measures just a few hundredths of a millimeter. With the help of electrostatic fields, each individual micromirror can be tilted up to 5,000 times per second. Depending on the setting, the LED light is either directed via the lenses onto the road or is absorbed in order to mask out areas of the light beam.

In the Audi e-tron Sportback, the digital light that will expand the offering in mid-2020, performs multiple tasks. It can generate dynamic leaving- and coming-home animations that appear as projections on a wall or on the ground. This presentation transforms the area in front of the car into a carefully illuminated stage. Not only does the digital light system deliver cornering, city, and highway lighting as versions of the low-beam light with exceptional precision, it also supplements the high-beam light by masking out other road users with even greater accuracy. Above all, however, it offers innovative functions such as lane light and orientation light. On freeways, the lane light creates a carpet of light that illuminates the driver’s own lane brightly and adjusts dynamically when he or she changes lane. In this way, it improves the driver’s awareness of the relevant lane and contributes to improved road safety. In addition, the orientation light uses darkened areas masked out from the light beam to predictively show the vehicle’s position in the lane, thereby supporting—especially on narrow roads or in highway construction zones—the safe lane centering assist. The marking light function is also used in conjunction with the optional night vision assist. The light automatically draws attention to any pedestrians it detects, thereby reducing the danger of overlooking pedestrians in the immediate vicinity of the lane.

LED headlights Audi Q3 (2014)

LED headlights

Along with their high level of efficiency, LED headlights also offer significant benefits in terms of safety and comfort. With a color temperature of around 5,500 Kelvin, their light resembles daylight and hardly causes any eye fatigue – especially in the dark and in the case of adverse weather conditions. In addition, LED headlights offer longer visual range than xenon headlights. In fog and precipitation, they cause the driver less glare. The LEDs are maintenance-free and designed to last the life of the car. The give the Audi models a distinctive look and strong accents with their innovative daytime and nighttime designs.

Depending on the model the LED headlights are designed differently. In the Audi A5, for example, 26 LEDs per headlight generate all lighting functions. In each headlight, 14 LEDs work together to generate the low and high beam lights, and they are supplemented by a module for the all-weather and turning lights. A light conductor along the upper border of the headlight generates the daytime running lights, parking lights and turn signal lights. Special illumination functions are available for intersections, country roads, expressways and poor weather – and their interplay with the navigation system makes their range of performance even greater.

(HD) Matrix LED headlights

(HD) Matrix LED headlights

Matrix LED headlights produce the high beam with tiny light-emitting diodes that are bundled in common reflectors or lenses, depending on the model. With their intelligent function, they illuminate the road superbly without blinding other road users.

When the light switch is set to Automatic and the high beams are on, the system is switched on outside of urban areas at speeds of 30 km/h (18.6 mph) and above. As soon as the camera on the windshield detects other vehicles or city limits, the controller switches off individual LEDs or dims them in 64 stages, creating several million possible light patterns. The Matrix LED light masks out other vehicles while continuing to fully illuminate the zones between and adjacent to them.

The LEDs in the Matrix LED headlights also assume the function of cornering lights, shifting the focal point of the light along the curve. This occurs shortly before the wheel is turned, based on predictive route data provided by MMI navigation plus.

Audi introduced the next development stage of this technology, the HD Matrix LED high beam, in the A8 (D5). Each headlight integrates 32 small, individually controllable light-emitting diodes. They are arranged in two rows in a common housing. Thanks to the new configuration and to a low beam that is also variable, the HD Matrix LED headlights illuminate the road particularly dynamically and precisely.

OLED rear lights Audi TT RS (2016)

OLED rear lights

In some models Audi uses rear lights in OLED technology (OLED: organic light-emitting diode). In each unit, two electrodes – at least one of which is transparent – incorporate numerous extremely thin layers of organic semiconductor materials. A low DC voltage between 3 and 4 volts causes these layers, which are 200 times thinner than a human hair, to illuminate.

Unlike point light sources such as LEDs, OLEDs are surface light sources. Their light achieves a new level of homogeneity, and dimming is continuously variable. It does not cast any harsh shadows and does not require any reflectors, light guides or similar optical parts. This makes the OLED units efficient, lightweight and perfectly homogeneous.

In the Audi A8 (2017), each OLED unit is divided into multiple segments that light up with varying brightness. The outer corners generate the tail light, the inner surfaces generate the brake light. The illuminated surface sections are delimited from one another with extreme precision. Dividing the OLEDs into small, individually controllable segments arranged in three dimensions enables entirely new lighting scenarios.

Xenon headlights Audi A1 (2010)

Xenon headlights

Xenon headlights are gas discharge lamps. Two tungsten electrodes are fused into a thick-walled quartz glass bulb that is filled with xenon gas, also known as the burner. A concentrated arc of light is produced between them – a process in which the enclosed noble gas fill exerts a pressure of up to 100 bar. The xenon gas itself lights in more of a violet hue, but metallic salts contained in the glass bulb reduce its color temperature to 4,200 Kelvin.

Xenon headlights deliver a much brighter light and achieve better illumination of the roadway than halogen lights with incandescent bulbs. Their energy consumption – including the energy consumed by the ballast unit – is around 20 percent lower, and their life is much longer. Audi offers what are known as xenon plus headlights in some models. Here a single burner generates both the low and high beams, and they are switched by a movable shutter.
