Compared to its direct predecessor, a naturally aspirated high-speed V8 engine, the re-developed V6 twin turbo delivers a completely new dimension of torque and efficiency. From 1,900 to 5,000 rpm, the 2.9 TFSI engine delivers a full 600 Nm (442.5 lb-ft) of torque to the crankshaft – 170 Nm (125.4 lb-ft) more than its predecessor. With its output of 331 kW (450 hp), equating to a performance of 155.5 hp per liter, the new RS 4 Avant accelerates from zero to 100 km/h (0 to 60 mph) in 4.1 seconds, which is 0.6 tenths of a second faster than before. The RS dynamics package increases the electronically controlled top speed from 250 km/h (155.3 mph) to 280 km/h (174 mph).

The 2.9 TFSI V6 twin turbo engine from Audi Sport is a nod to the legendary 2.7 liter V6 from the first RS 4 Avant. Produced from 1999 to 2001, it delivered 279 kW (380 hp).

AUDI RS 4 Avant

2.9 TFSI

Displacement in ccm


Max. power in kW (hp) at rpm

331 (450) at 5,700–6,700

Max. torque in Nm (lb-ft) at rpm

600 (442.5) at 1,900–5,000

Maximum speed in km/h (mph)

250 (155.3), optional 280 (174)

Acceleration 0 to 100 km/h in s (0 to 60 mph)


Combined consumption in l/100 km (US mpg)

8.8 (26.7)

Combined CO2 emissions in g/km (g/mi)

200–199 (321.9-320.3)


quattro permanent all-wheel drive


Eight-speed tiptronic

Modular concept: The new V6 generation
Owing to the higher forces in its interior, its stroke was reduced by 3 millimeters (0.1 in) to 86 millimeters (3.4 in). With an unchanged bore hole of 84 millimeters (3.3 in), the displacement measures 2,894 cm3. The engine only weighs 182 kilograms (401.2 lbs), which is 31 kilograms (68.3 lbs) less than its V8 predecessor, which benefits the overall weight and axle load distribution of the new Audi RS 4 Avant (combined fuel consumption in l/100 km: 8.8 [26.7 US mpg]; combined CO2 emissions in g/km: 200–199 [321.9–320.3 g/mi]).

Typical Audi: Exhaust side inside, intake side outside
The two turbochargers of the 2.9 TFSI are each arranged on a cylinder bank, and generate up to 1.5 bar of charge pressure. As with all new V6 and V8 engines from Audi, the turbochargers are mounted at a 90-degree angle to the cylinder banks, which means that the exhaust side of the cylinder heads is inside, and the intake side is outside. This layout enables a compact design and short fuel paths with minimal flow loss – the 2.9 TFSI reacts extremely spontaneously to the movements of the right pedal.

Efficiency technology: The B-cycle combustion process
The high-performance V6 not only impresses with its strong performance, but also its efficiency. In the new European driving cycle, the vehicle uses just 8.8 liters of fuel per 100 kilometers (26.7 US mpg), equivalent to 200–199 grams of CO2 per kilometer (321.9–320.3 g/mi). These values represent a 17% reduction in fuel consumption compared with the previous model. A key reason for this is the new TFSI combustion process from Audi called the B-cycle process. This is specially designed for the partial load range, by far the most common operating mode.

At higher loads and engine speeds, the two-step Audi valvelift system (AVS)closes the inlet valves later – the opening duration extends to 200 crank angle degrees. At the same time, the valve lift increases from 6.0 (0.2 in) to 10 millimeters (0.4 in). The cylinder filling increases considerably – the engine turns at a powerfully high speed and delivers smooth performance.

Separate circuits: The thermal management system
Another factor in the efficiency of the 2.9 TFSI is the thermal management system. The crankcase and the cylinder head have separate cooling circuits. After a cold start, the switchable water pump regulates the flow of coolant through the engine so that the oil heats up quickly. The exhaust manifolds are integrated into the cylinder heads, and are surrounded by the coolant, which helps to accelerate the heating process. When the engine is warm, this technology lowers the exhaust gas temperature – which significantly reduces consumption, especially during sporty driving. The impressive efficiency of the V6 twin turbo is also a result of the low friction. The fully-variable oil pump, for example, only ever generates as much pressure as necessary.

With the chain drive, a new concept reduces the required drive power: The crankshaft drives the balancer shaft, which sits deep in the V of the cylinder banks, via gearwheels. From here, chains run to the four camshaft sprockets. They are tri-oval in shape, that is, slightly triangular, in order to balance out the peak forces. The balancer shaft rotates on particularly low-friction roller bearings.

Striking: The sound of the V6 twin turbo

As soon as the engine starts, it delivers a powerful sound. At higher loads, the flaps open in the exhaust system, and the sound is even throatier. With the Audi drive select dynamic handling system, which comes as standard, the driver can also control the flaps – both for the standard RS exhaust system and for the optional RS sports exhaust system with black tail trims. The intake system of the V6 twin turbo has been intricately optimized, with pipes made from polished stainless steel allowing the air to flow in virtually unobstructed.
